For fast operation with frequent soft starts and stops.
Brand
Megadoor
The first Megadoor vertical lifting fabric door was developed in 1973 as a kiln door for the forestry industry, where extra-large doors with good insulation were especially needed. In 2012 Cardo, the parent company of both Megadoor and Crawford was acquired by ASSA ABLOY Group.
View brandThe ASSA ABLOY VL3110FCS Megadoor vertical-lifting fabric door delivers rapid performance in tough industrial environments. It’s an ideal choice for speed, but also for protection against wind, moisture and much more.
The unique design and structure offers durability, tightness, energy efficiency, operational reliability and minimum maintenance. Every door is individually designed to meet application requirements, for example high wind load.
Technical Description
ASSA ABLOY VL3110FCS*
- Max size (W/H) [1]: 6000x6000 mm
- Door leaf thickness thickness: 100 mm
- Guide rails material: aluminum
- Vision panels; optional
- Wind load resistance: 0.7-1.6 kPa depending on size, (Differential pressure class 3-5, EN 12424)
- Sound reduction (standard): 15 dB Rw (ISO 717)
- Water resistance, EN 12425: class 3
- Air permeability, EN 12426: class 2
- Thermal transmittance, EN 12428: depending on door size, specific data on request
- Opening speed: up to 1,5 m/s
- Closing speed: up to 0,35 m/s
- Operating environment temperature range: -35°C to +70°C
[1] Other sizes may be available on request
