ASSA ABLOY DL6020T
ASSA ABLOY DL6020T
Enable optimal load utilization of the vehicle bed area.
Brand
Crawford
In 2011 Cardo, the parent company of both Crawford and Megadoor was acquired by ASSA ABLOY Group and both are now product brands of ASSA ABLOY Entrance Systems.
View brandHydraulic telescopic lip-dock levelers have a movable telescopic lip, which provides a larger contact area between vehicle bed and dock leveller. Thanks to that, they can be precisely positioned on the vehicle bed for optimal load utilization and increased safety. Preventive maintenance is easy and fast to secure functionality. All hydraulic telescopic lip-dock levelers are easy and comfortable to operate.
The innovative and unique ASSA ABLOY 950 series docking control system offers perfect control of the dock leveller, dock shelter and door, all in one control unit. A few self-explaining buttons make the system easy to operate. Separate steering units or complex wiring are no longer needed.
ASSA ABLOY DL6020T teledock
ASSA ABLOY DL6020T teledock is the universal and most flexible docking system. It is suitable for every loading situation – regardless of its complexity. An optional Ergonomic Lip gives absolutely bump free transition from the leveler platform to the lip. This makes the ASSA ABLOY DL6020T teledock ideal for operations with electrical pallet trucks without spring bumpers.
ASSA ABLOY DL6020TA teledock autodock*
ASSA ABLOY DL6020TA teledock autodock has a self-supporting frame for easy integration with a building. It forms a base for a complete loadhouse outside the building, containing all relevant components, leveler, shelter and door to make it a total docking solution. An optional Ergonomic Lip gives absolutely bump free transition from the leveler platform to the lip. This makes the ASSA ABLOY DL6020TA teledock autodock ideal for operations with electrical pallet trucks without spring bumpers.
ASSA ABLOY DL6021T teledock 100*
ASSA ABLOY DL6021T teledock 100 is a heavy-duty telescopic lip-dock leveller with a load capacity of 100 kN. Robust and reliable construction guarantees high performance during the tough handling of high loads.
Imported products are marked with "*"
Technical Description
ASSA ABLOY DL6120T
- Normal length: 2000, 2500, 3000, 3500, 4000, 4500 mm
- Normal width: 1750, 2000, 2200, 2250 mm
- Load capacity: 60 kN (6 tonnes)
- Vertical working range: Rise above dock up to 660mm, Fall below dock down to 440mm
- Platform tear-plate thickness: 8/10mm
- Max point load leveler platform: 6,5 N/mm² (8 mm tear plate)
- Lip type and length: telescopic, 500/1000 mm ergonomic lip, 345 mm
- Lip material: steel or aluminium
- Lip option: tapered lip / Retracting tongues
- Control unit protection class: IP 54
- Temperature range hydraulic oil: -20°C - +60°C
- European standard: EN1398 dock levelers
ASSA ABLOY DL6020TA*
- Normal length: 2000, 2450, 3000 mm (other sizes on request)
- Normal width: 3300, 3500, 3600, 3750 mm
- Load capacity: 60 kN (6 tonnes)
- Vertical working range: Rise above dock up to 520mm, Fall below dock down to 470mm
- Platform tear-plate thickness: 8/10mm
- Max point load leveler platform: 6,5 N/mm² (8 mm tear plate)
- Lip type and length: telescopic, 500/1000 mm ergonomic lip, 345 mm
- Lip material: steel or aluminium
- Lip option: tapered lip / Retracting tongues
- Control unit protection class: IP 54
- Temperature range hydraulic oil: -20°C - +60°C
- European standard: EN1398 dock leveler
ASSA ABLOY DL6021T*
- Normal length: 2000, 2500, 3000, 3500, 4000, 4500 mm
- Normal width: 2000, 2200 mm
- Load capacity: 100 kN (10 tonnes)
- Vertical working range: Rise above dock up to 550mm, Fall below dock down to 400mm
- Platform tear-plate thickness: 10/12mm
- Max point load leveler platform: 6,5 N/mm² (10 mm tear plate)
- Control unit protection class: IP 54
- Temperature range hydraulic oil: -20°C - +60°C
- Magnetic valves: 24 V / DC 18W S1
- Nominal voltage: 400V 3-phase, 230V 3-phase
- European standard: EN1398 dock levelers
