ASSA ABLOY SL500 Frame
ASSA ABLOY SL500 Frame
ASSA ABLOY SL500 Frame's rugged design makes it suitable for use in high-traffic entrances where shopping trolleys are passing in and out.
Brand
Besam
Besam was acquired by ASSA ABLOY in 2002 and is now a product brand of ASSA ABLOY Entrance Systems.
View brandASSA ABLOY SL500 Frame
ASSA ABLOY SL500 Frame's rugged design makes it suitable for use in high-traffic entrances where shopping trolleys are passing in and out. It’s supplied as a complete system including the doors, operator, safety devices, and if required, side screens and overlights. The Frame sliding door system is available for beam or wall mounting and can be supplied as a bi-parting or single sliding door. The aluminium profiles are clear anodized and glazed with 6mm+9mm+6mm laminated glass as standard.
The Frame sliding door can be equipped with an optional BreakOut feature that allows exit through the entire door opening and side-screen space in the case of an emergency. A Reverse BreakOut option is available for installations without side screens. A tight-seal add-on improves the energy savings.
ASSA ABLOY SL500 Frame Telescopic
The ASSA ABLOY SL500 Frame Telescopic is the natural choice for narrow passageways because it maximizes the width of the door opening, providing an impressive solution where space is limited. Its rugged design makes this solution suitable for use in areas with high traffic and where shopping trolleys are passing in and out. The Frame Telescopic is supplied as a complete system including the doors, operator, safety units and, if required, side screens and overlights.
Technical Description
ASSA ABLOY SL500 Frame / Frame Thermo
- Profile type:
Frame
Frame Eco (thermally broken profile) - Profile finish:
anodized aluminium, colour on request
painted in colour according to RAL card - Glass type:
6, 8 or 10 mm laminated (Frame only)
6, 8 or 10 mm tempered (Frame only)
22 or 40 mm insulated glass - Glass finish: clear, green, bronze, opaque
- Overlight (beam mounted only)
- Side screens
- Mechanical lock
